Attitude information is displayed over a virtual blue sky and brown ground with a white horizon line, which is also part of the pitch scale. Pitch markings are spaced at 2.5-degree intervals and a yellow symbolic aircraft corresponds to the current pitch attitude. A slip/skid indicator is positioned at the bottom of the display, along with a magenta turn rate trend vector. Missing on the STCd G5, but standard on the version for experimental aircraft, is a flight director command bar presentation because autopilot input is excluded from the STC.
